Mono Layer Extruder Machine (SGT-32):
- Flender Germany made gear box
- Main Motor direct connection with gear box, saving power consumption
- L/D: 30/1, SACM645 Screw & barrel, HRC 65
- Spiral type die head fir stretch film making
- High efficiency dual lip air ring
- Pneumatic take- up unit, equipped AC motor with inverter control
- In-line film tension control system
- Mechanics surface friction back to back winder
- Precious SSR +PID temperature controller
| MODEL | SGT-40 |
| WIDTH OF LAYFLAT | 610 MM |
| EXTRUDER | |
| SCREW DIA | 40 MM |
| SCREW RATIO | 27 L/D |
| MAIN MOTOR | 7.5(10) KW(HP) |
| HEATER CAPACITY | 5.7 KW |
| SCREW RPM | 0-90 |
| OUT PUT | 35 KG/HR |
| DIE | |
| DIE SIZE (1) | HDPE DIA 25-75 MM |
| DIE SIZE (2) | LDPE DIA 25-100 MM |
| FILTER TYPE | CANDLE |
| HEATER CAPACITY | 6.85 KW |
| TAKE OFF | |
| NIP ROLL SIZE | 26” INCH |
| MAIN SIZE | 0.75(1) KW(HP) |
| WINDER | |
| TOTAL HEATING LOAD | 13.55 KW |
| TOTAL CONNECTED LOAD | 23.5 KW |
| SPACE REQUIREMENT L*W*H | 2.3*2.3*3.4 |
